Suction blow composite conveyor
- Model
- EDLCF-36-2;EDLC F-53-4;EDLC F–56-6
Item specifics
- Model number
- EDLCF-36-2
- Discharging caliber
- 150mm
- Suction feeding pipe diameter
- DN40
- Conveying distance
- 10-100m
- Delivery pressure
- <0.08MPa
Review
Description
Product Description
Features
1, Easy to take materials, suitable for low-level, deep or narrow reclaiming points and requirements do not produce dust.
2, Can meet the conditions of several places to a centralized feeding, or several places to concentrate after a centralized and more feeding conditions.
3, Using the Roots blower to do the same power source, while meeting the vacuum and positive pressure power supply, reducing energy consumption and maintenance costs. 4, continuous delivery, easy to control.
Product Specification
|
Type
|
Delivery value
T/H |
Discharging caliber mm | Conveying pipe diameter mm | ||
|
EDLCF-36-2 |
0.5-2t/h |
150mm | DN40 | 10-100m | <0.08MPa |
EDLC F-53-4 | 1-3t/h | 180 mm | DN50 | ||
EDLC F–56-6 | 2-5t/h | 200 mm | DN65 | ||
EDLC F-64-8 | 3-7t/h | 220 mm | DN80 | ||
EDLCF -66-12 | 5-10t/h | 260 mm | DN80 | ||
EDLCF -86-16 | 8-13 t/h | 300 mm | DN100 | ||
EDLCF -116-20 | 11-20 t/h | 340 mm | DN100 | ||
EDLCF -136-26 | 15-25 t/h | 400 mm | DN125 | ||
EDLCF -166-40 | 20-40t/h | 500 mm | DN125 |
Detail Images
Company Information
After years of unremitting efforts, the company has promoted powder material conveying technology to many fields such as pharmaceutical, food, chemical, etc., through a large number of powder conveying test and a variety of material transport cases, in the powder material transport process has The unique advantage can meet the various transportation needs of different customers, help customers to improve the process, improve the quality and efficiency of the company's products, and is recognized by the company and praised by customers.
Based on the principle of “customer first, honesty and technology first”, the company can solve your technical problems and guarantee the world advanced and reliable equipment. We sincerely hope to cooperate with you.
